#include <BioSocketBase.h>

Public Types
enum	format { pf_unspec = PF_UNSPEC, pf_unix = PF_UNIX, pf_inet = PF_INET, pf_max = PF_MAX }
	Address format specifications, for the create() member. More...
enum	type { sock_stream = SOCK_STREAM, sock_dgram = SOCK_DGRAM, sock_raw = SOCK_RAW, sock_rdm = SOCK_RDM, sock_seqpacket = SOCK_SEQPACKET }
	Type specification for the create() method. More...
enum	protocol { proto_ip = IPPROTO_IP, proto_icmp = IPPROTO_ICMP, proto_tcp = IPPROTO_TCP, proto_pup = IPPROTO_PUP, proto_udp = IPPROTO_UDP, proto_idp = IPPROTO_IDP, proto_raw = IPPROTO_RAW, proto_max = IPPROTO_MAX }
	Protocol to be used on this socket. More...
enum	{ invalid_socket = INVALID_SOCKET }
enum	msgflag { msg_none = 0, msg_oob = MSG_OOB, msg_peek = MSG_PEEK, msg_dontroute = MSG_DONTROUTE }
	Flags to use with recv/send methods. More...
enum	shuthow { shut_recv = 0, shut_send = 1, shut_both = 2 }
	Flags for the shutdown() method. More...
enum	errors { socket_error = SOCKET_ERROR, eintr = WSAEINTR, ebadf = WSAEBADF, eacces = WSAEACCES, efault = WSAEFAULT, einval = WSAEINVAL, emfile = WSAEMFILE, ewouldblock = WSAEWOULDBLOCK, einprogress = WSAEINPROGRESS, ealready = WSAEALREADY, enotsock = WSAENOTSOCK, edestaddrreq = WSAEDESTADDRREQ, emsgsize = WSAEMSGSIZE, eprototype = WSAEPROTOTYPE, enoprotoopt = WSAENOPROTOOPT, eprotonosupport = WSAEPROTONOSUPPORT, esocktnotsupport = WSAESOCKTNOSUPPORT, eopnotsupp = WSAEOPNOTSUPP, epfnosupport = WSAEPFNOSUPPORT, afnosupport = WSAEAFNOSUPPORT, eaddrinuse = WSAEADDRINUSE, eaddrnotavail = WSAEADDRNOTAVAIL, enetdown = WSAENETDOWN, enetunreach = WSAENETUNREACH, enetreset = WSAENETRESET, econnaborted = WSAECONNABORTED, econnreset = WSAECONNRESET, enobufs = WSAENOBUFS, eisconn = WSAEISCONN, enotconn = WSAENOTCONN, eshutdown = WSAESHUTDOWN, etoomanyrefs = WSAETOOMANYREFS, etimedout = WSAETIMEDOUT, econnrefused = WSAECONNREFUSED, eloop = WSAELOOP, enametoolong = WSAENAMETOOLONG, ehostdown = WSAEHOSTDOWN, ehostunreach = WSAEHOSTUNREACH, host_not_found = WSAHOST_NOT_FOUND, try_again = WSATRY_AGAIN, no_recovery = WSANO_RECOVERY, no_data = WSANO_DATA }
	Errors that may be set by the different socklibpp::sock operations. More...
enum	ioctl_cmd { fionbio = FIONBIO, fionread = FIONREAD, siocatmark = SIOCATMARK }
	Flags to use in the sock::ioctl method. More...
enum	mode { passive, active }
	Flags to use in the convenience constructor. More...
enum	optlevel { sol_socket = SOL_SOCKET, ipproto_tcp = IPPROTO_TCP }
	Levels of socket options for the getsockopt/setsockopt methods. More...
enum	optname { so_acceptconn = SO_ACCEPTCONN, so_broadcast = SO_BROADCAST, so_debug = SO_DEBUG, so_dontroute = SO_DONTROUTE, so_error = SO_ERROR, so_keepalive = SO_KEEPALIVE, so_linger = SO_LINGER, so_oobinline = SO_OOBINLINE, so_rcvbuf = SO_RCVBUF, so_reuseaddr = SO_REUSEADDR, so_sndbuf = SO_SNDBUF, so_type = SO_TYPE, tcp_nodelay = TCP_NODELAY }
	Option names for the getsockopt/setsockopt methods. More...
enum	selectstate { readable = 1, writable = 2, exceptable = 4 }
	select() results More...
Public Member Functions
	BioSocket () throw ()
	Default constructor.
	BioSocket (socket_type fd_) throw ()
	Constructor that uses an already created socket descriptor.
	BioSocket (format, type, protocol=proto_ip) throw ()
	Constructs and allocates a new socket.
BioSocket	accept () throw ()
	Accept incomming connections in a listening socket.
BioSocket	accept (BioSocketAddress &) throw ()
	Accepts incomming connections in a listening socket and stores the accepted address.
bool	bind (const BioSocketAddress &) throw ()
	Bind the socket to a specific address.
bool	close () throw ()
	Close the socket, releasing the resources used by it.
bool	connect (const BioSocketAddress &) throw ()
	Create a connection to the specified address.
bool	peername (BioSocketAddress &) const throw ()
	Get the address of the peer at which the socket is connected.
bool	sockname (BioSocketAddress &) throw ()
	Get the local address of the socket.
bool	getsockopt (optlevel, optname, int &) const throw ()
	Retrieve a socket option.
bool	getsockopt (optlevel, optname, bool &) const throw ()
	Retrieve a socket option.
bool	ioctl (ioctl_cmd, unsigned long &) throw ()
	Control the mode of a socket.
bool	listen (int=3) throw ()
	Put the socket in passive (listen) mode for incomming connections.
int	recv (char *, int, msgflag=msg_none) throw ()
	Receive data from a socket.
int	recvfrom (BioSocketAddress &, char *, int, msgflag=msg_none) throw ()
	Receive a datagram and store the source address.
bool	can_read (long=0, long=0) const throw ()
	Check if the socket has data to be read.
bool	wait_read (long &, long &) const throw ()
	Wait until data can be read.
bool	wait_read () const throw ()
	Wait until data can be read.
bool	can_write (int=0, int=0) throw ()
	Check if the socket can be written to.
bool	can_except (int=0, int=0) throw ()
	Checks for the presence of out-of-band data or if any exceptional error conditions.
unsigned	select (int=0, int=0) throw ()
	Do a normal select(), returning the state of the socket.
int	send (const char *, int, msgflag=msg_none) throw ()
	Send data on a connected socket.
int	sendto (const BioSocketAddress &, const char *, int, msgflag=msg_none) throw ()
	Send data to a specific destination.
bool	setsockopt (optlevel, optname, int) throw ()
	Set a socket option.
bool	shutdown (shuthow) throw ()
	Disable sends and/or receives on a socket.
bool	create (format, type, protocol=proto_ip) throw ()
	Create a new socket.
bool	socket (format fmt, type tp, protocol pr=proto_ip) throw ()
	Synonym for create()
bool	sendall (const char *, int, msgflag=msg_none) throw ()
	Send all data.
bool	recvall (char *, int, msgflag=msg_none) throw ()
	Recv all data.
bool	block (bool) throw ()
	Set the blocking mode.
bool	reuseaddr () const throw ()
	Query if it can reuse the addr.
bool	reuseaddr (bool) throw ()
	Set the reuse addr option.
int	sendbuf () const throw ()
	Get the size of the internal send buffer.
void	sendbuf (int) throw ()
	Set the size of the internal send buffer.
int	recvbuf () const throw ()
	Get the size of the internal recv buffer.
void	recvbuf (int) throw ()
	Set the size of the internal recv buffer.
Public Attributes
socket_type	fd
	The descriptor of this socket.
int	error
	The error code of the last operation performed.

Member Enumeration Documentation

anonymous enum

Enumerator:

invalid_socket

An invalid socket.

enum BioSocket::errors

Errors that may be set by the different socklibpp::sock operations.

Enumerator:

socket_error	Error value used as result for some functions.
eintr
ebadf
eacces
efault
einval
emfile
ewouldblock	The requested operation would block, try again later.
einprogress
ealready
enotsock
edestaddrreq
emsgsize
eprototype
enoprotoopt
eprotonosupport
esocktnotsupport
eopnotsupp
epfnosupport
afnosupport
eaddrinuse
eaddrnotavail
enetdown
enetunreach
enetreset
econnaborted
econnreset
enobufs
eisconn
enotconn
eshutdown
etoomanyrefs
etimedout
econnrefused
eloop
enametoolong
ehostdown
ehostunreach
host_not_found
try_again
no_recovery
no_data

enum BioSocket::format

Address format specifications, for the create() member.

Enumerator:

pf_unspec	Unspecified.
pf_unix	Unix pipes.
pf_inet	IPv4 format.
pf_max	not used

enum BioSocket::ioctl_cmd

Flags to use in the sock::ioctl method.

Enumerator:

fionbio	Enable or disable non-blocking mode on the socket.
fionread	Determine the amount of data which can be read atomically from socket.
siocatmark	Determine whether or not all out-of-band data has been read.

enum BioSocket::mode

Flags to use in the convenience constructor.

Enumerator:

passive	Create a sock_stream socket and put it in listen mode.
active	Create a sock_stream socket and connect it.

enum BioSocket::msgflag

Flags to use with recv/send methods.

Enumerator:

msg_none	Default.
msg_oob	send/recv out-of-band data (sock_stream only).
msg_peek	Peek at the incoming data.
msg_dontroute	Should not be subject to routing.

enum BioSocket::optlevel

Levels of socket options for the getsockopt/setsockopt methods.

Enumerator:

sol_socket
ipproto_tcp

enum BioSocket::optname

Option names for the getsockopt/setsockopt methods.

Enumerator:

so_acceptconn	(bool) Socket is listen()ing.
so_broadcast	(bool) Socket is configured for the transmission of broadcast messages.
so_debug	(bool) Debugging is enabled.
so_dontroute	(bool) Routing is disabled.
so_error	(int) Retrieve error status and clear.
so_keepalive	(bool Keepalives are being sent.
so_linger	(struct linger *) Returns the current linger options.
so_oobinline	(bool) Out-of-band data is being received in the normal data stream.
so_rcvbuf	(int) Buffer size for receives
so_reuseaddr	(bool) The socket may be bound to an address which is already in use.
so_sndbuf	(int) Buffer size for sends
so_type	(int) The type of the socket (e.g. sock_stream).
tcp_nodelay	(bool) Disables the Nagle algorithm for send coalescing.

enum BioSocket::protocol

Protocol to be used on this socket.

Enumerator:

proto_ip	Default protocol for the specified socket type.
proto_icmp	ICMP.
proto_tcp	TCP.
proto_pup	PUP.
proto_udp	UDP.
proto_idp	IDP.
proto_raw	RAW.
proto_max	not used

enum BioSocket::selectstate

select() results

Enumerator:

readable	there is data waiting to be read
writable	socket can be written to without blocking
exceptable	there is an exceptional event pending

enum BioSocket::shuthow

Flags for the shutdown() method.

Enumerator:

shut_recv	Disallows further recv() calls.
shut_send	Disallows further send() calls.
shut_both	Disallows both send() and recv() calls.

enum BioSocket::type

Type specification for the create() method.

Enumerator:

sock_stream	Stream sockets (TCP)
sock_dgram	Datagram sockets.
sock_raw	Raw sockets.
sock_rdm
sock_seqpacket

Constructor & Destructor Documentation

BioSocket::BioSocket ( ) throw () [inline]

Default constructor.

It doesn't allocate resources for a socket, you have to call create() to actually allocate a socket.

See also:: create()

BioSocket::BioSocket ( socket_type fd_ ) throw () [inline]

Constructor that uses an already created socket descriptor.

Parameters:

_fd	a socket_type descriptor.

BioSocket::BioSocket	(	format	,
		type	,
		protocol	= `proto_ip`
	)		throw ()

Constructs and allocates a new socket.

Member Function Documentation

BioSocket BioSocket::accept ( ) throw ()

Accept incomming connections in a listening socket.

BioSocket BioSocket::accept ( BioSocketAddress & ) throw ()

Accepts incomming connections in a listening socket and stores the accepted address.

bool BioSocket::bind ( const BioSocketAddress & ) throw ()

Bind the socket to a specific address.

bool BioSocket::block ( bool ) throw ()

Set the blocking mode.

bool BioSocket::can_except	(	int	= `0`,
		int	= `0`
	)		throw ()

Checks for the presence of out-of-band data or if any exceptional error conditions.

bool BioSocket::can_read	(	long	= `0`,
		long	= `0`
	)		const throw ()

Check if the socket has data to be read.

Here is the caller graph for this function:

bool BioSocket::can_write	(	int	= `0`,
		int	= `0`
	)		throw ()

Check if the socket can be written to.

Here is the caller graph for this function:

bool BioSocket::close ( ) throw ()

Close the socket, releasing the resources used by it.

Here is the caller graph for this function:

bool BioSocket::connect ( const BioSocketAddress & ) throw ()

Create a connection to the specified address.

Here is the caller graph for this function:

bool BioSocket::create	(	format	,
		type	,
		protocol	= `proto_ip`
	)		throw ()

Create a new socket.

Here is the caller graph for this function:

bool BioSocket::getsockopt	(	optlevel	,
		optname	,
		int &
	)		const throw ()

Retrieve a socket option.

bool BioSocket::getsockopt	(	optlevel	,
		optname	,
		bool &
	)		const throw ()

Retrieve a socket option.

bool BioSocket::ioctl	(	ioctl_cmd	,
		unsigned long &
	)		throw ()

Control the mode of a socket.

Here is the caller graph for this function:

bool BioSocket::listen ( int = 3 ) throw ()

Put the socket in passive (listen) mode for incomming connections.

bool BioSocket::peername ( BioSocketAddress & ) const throw ()

Get the address of the peer at which the socket is connected.

Here is the caller graph for this function:

int BioSocket::recv	(	char *	,
		int	,
		msgflag	= `msg_none`
	)		throw ()

Receive data from a socket.

Here is the caller graph for this function:

bool BioSocket::recvall	(	char *	,
		int	,
		msgflag	= `msg_none`
	)		throw ()

Recv all data.

int BioSocket::recvbuf ( ) const throw ()

Get the size of the internal recv buffer.

void BioSocket::recvbuf ( int ) throw ()

Set the size of the internal recv buffer.

int BioSocket::recvfrom	(	BioSocketAddress &	,
		char *	,
		int	,
		msgflag	= `msg_none`
	)		throw ()

Receive a datagram and store the source address.

bool BioSocket::reuseaddr ( ) const throw ()

Query if it can reuse the addr.

bool BioSocket::reuseaddr ( bool ) throw ()

Set the reuse addr option.

unsigned BioSocket::select	(	int	= `0`,
		int	= `0`
	)		throw ()

Do a normal select(), returning the state of the socket.

int BioSocket::send	(	const char *	,
		int	,
		msgflag	= `msg_none`
	)		throw ()

Send data on a connected socket.

Here is the caller graph for this function:

bool BioSocket::sendall	(	const char *	,
		int	,
		msgflag	= `msg_none`
	)		throw ()

Send all data.

int BioSocket::sendbuf ( ) const throw ()

Get the size of the internal send buffer.

void BioSocket::sendbuf ( int ) throw ()

Set the size of the internal send buffer.

int BioSocket::sendto	(	const BioSocketAddress &	,
		const char *	,
		int	,
		msgflag	= `msg_none`
	)		throw ()

Send data to a specific destination.

bool BioSocket::setsockopt	(	optlevel	,
		optname	,
		int
	)		throw ()

Set a socket option.

bool BioSocket::shutdown ( shuthow ) throw ()

Disable sends and/or receives on a socket.

bool BioSocket::socket	(	format	fmt,
		type	tp,
		protocol	pr = `proto_ip`
	)		throw () `[inline]`

Synonym for create()

Here is the call graph for this function:

bool BioSocket::sockname ( BioSocketAddress & ) throw ()

Get the local address of the socket.

bool BioSocket::wait_read	(	long &	,
		long &
	)		const throw ()

Wait until data can be read.

bool BioSocket::wait_read ( ) const throw ()

Wait until data can be read.

Member Data Documentation

int BioSocket::error [mutable]

The error code of the last operation performed.

If no error ocurred in the last operation, the value is zero.

Note:: For some operations this is the only way to detect if an error ocurred. e.g. accept()

socket_type BioSocket::fd

The descriptor of this socket.

This usually have the size of an int, but may be signed or unsigned depending on the platform. You should never use < or > to compare it with any other value. The only useful value to compare is socklibpp::sock::invalid_socket, and you should always test using == or !=.

The documentation for this struct was generated from the following file:

BioSocketBase.h

Public Types

Public Member Functions

Public Attributes

Member Enumeration Documentation

Constructor & Destructor Documentation

Member Function Documentation

Member Data Documentation
